1 Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
2 Wind load: max. 100km/h (can be reinforced)
3 Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)
4 Easy to be assembled and dismantled, movable
5 No pole inside, 100% room is available
6 Sizes can be customized
Application:
Widely used for Exhibition, Wedding, Temporary warehouse
Event, Party, Banquet, Parking, Marquee
Frame materials:
Hard pressed extruded aluminium 6063/T6
Roof cover:
Double PVC coated polyester fabric
Water-proof, snow-proof, flame retardant to DIN 4102 B1, M2
Weight: 850G/square meter
Color available: Yellow, white, red, blue
Side wall:
Double PVC coated polyester fabric
Sidewall with with transparent PVC arched windows and lining
Water-proof, snow-proof, flame retardant to DIN 4102 B1, M2
Weight: 650G/square meter
Color available: Yellow, white, red, blue
Width
The clear-span could be 3M(9.84feet)----30M(98.4feet)
Length
The length could be customized, 10M, 15M, 20M, +5Mmore^^^...
Feature
No bearing column in the middle of the structure, you can use the space fully.
Equipment
You can fit with doors, air conditioner, lighting system, wood floor, carpet, tables, chairs, and so
On
Characteristic
With the merits of fast to set up and dismantle, Small volume after taken down which convenient to stock and transport which is know as the real mobile estate.
Package
Package: Protected by bubble paper or bag, and as usual shipment package
Related Products
Tent Accessories
Our Company
2 Wind load: max. 100km/h (can be reinforced)
3 Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)
4 Easy to be assembled and dismantled, movable
5 No pole inside, 100% room is available
6 Sizes can be customized
Application:
Widely used for Exhibition, Wedding, Temporary warehouse
Event, Party, Banquet, Parking, Marquee
Frame materials:
Hard pressed extruded aluminium 6063/T6
Roof cover:
Double PVC coated polyester fabric
Water-proof, snow-proof, flame retardant to DIN 4102 B1, M2
Weight: 850G/square meter
Color available: Yellow, white, red, blue
Side wall:
Double PVC coated polyester fabric
Sidewall with with transparent PVC arched windows and lining
Water-proof, snow-proof, flame retardant to DIN 4102 B1, M2
Weight: 650G/square meter
Color available: Yellow, white, red, blue
Width
The clear-span could be 3M(9.84feet)----30M(98.4feet)
Length
The length could be customized, 10M, 15M, 20M, +5Mmore^^^...
Feature
No bearing column in the middle of the structure, you can use the space fully.
Equipment
You can fit with doors, air conditioner, lighting system, wood floor, carpet, tables, chairs, and so
On
Characteristic
With the merits of fast to set up and dismantle, Small volume after taken down which convenient to stock and transport which is know as the real mobile estate.
Package
Package: Protected by bubble paper or bag, and as usual shipment package
| Product specification | Span width(m) | Bay spacing(m) | Eave height(m) | Ridge height(m) | Main frame profile (mm) |
| SBLP-3 | 3 | 3 | 2.5 | 3 | 48x84x3.0 |
| SBLP-6 | 6 | 3 | 2.5 | 3.5 | 48x84x3.0 |
| SBLP-8 | 8 | 3 | 2.5 | 3.9 | 48x84x3.0 |
| SBLP-10 | 10 | 3 | 2.5 | 4.3 | 48x84x3.0 |
| SBLP-15 | 15 | 5 | 4 | 6.4 | 150x108x3.0 |
| SBLP-18 | 18 | 5 | 4 | 6.9 | 203x112x4.5 |
| SBLP-21 | 21 | 5 | 4 | 7.4 | 203x112x4.5 |
| SBLP-25 | 25 | 5 | 4 | 8.0 | 203x112x4.5 |
| SBLP-30 | 30 | 5 | 4 | 8.8 | 113x259x5.5 |
